BACKER HOTWATT CATALOG

PRODUCTS

Hotwatt Part No.	West/McQuay Part No.	Wattage	Voltage	A”	B”
13J1405-1	350A412-1	250	115	9	36
13J1405-2	350A412-2	250	208	9	27
13J1405-3	350A412-3	250	230	8 7/8	27
13J1405-4	350A412-4	250	440	9	27
13J1405-5	350A412-5	250	550	9	27
13J1405-6	350A412-6	65	115	3 7/8	3
13J1405-7	350A412-7	65	230	3 7/8	3
13J1405-8	350A412-8	65	440	3 7/8	3
13J1405-9	350A412-9	65	550	3 7/8	3
13J1405-10	350A412-10	65	230	3 7/8	3
13J1405-11	350A412-11	65	440	3 7/8	3
13J1405-12	350A412-12	65	550	3 7/8	3
13J1405-13	350A412-13	250	400	9	27
13J1405-14	350A412-17	550	240	13 3/16	10
13J1405-15	350A412-29	350	115	6.5	36
13J1405-16	350A412-30	300	115	7.0	60
13J1405-17	350A412-32	300	115	7	72
13J1405-18	350A412-43	150	115	5 7/8	36
13J1405-19	350A412-46	200	230	2 1/2	60
13J1405-20	350A412-47	300	230	7	60
13J1405-21	350A412-48	300	115	7	60
13J1405-22	350A412-51	250	115	8 7/8	60
13J1405-23	350A412-52	200	115	2 1/2	60

Hotwatt Part No.	West/McQuay Part No.	Wattage	Voltage
13J2305-1	350A412-14	100	230
13J2305-2	350A412-15	100	440
13J2305-3	350A412-16	100	550
13J2305-4	350A412-34	100	120

Hotwatt Part No.	West/McQuay Part No.	Wattage	Voltage
13J2306-1	350A412-18	65	230
13J2306-2	350A412-19	65	440
13J2306-3	350A412-20	65	550

Hotwatt Part No.	West/McQuay Part No.	Wattage	Voltage	L”
13J1305-1	350A412-21	200	220	6
13J1305-2	350A412-22	200	440	6
13J1305-3	350A412-23	200	550	6
13J1305-4	350A412-24	350	220	10
13J1305-5	350A412-25	350	440	10
13J1305-6	350A412-26	350	550	10
13J1305-7	350A412-27	200	115	6
13J1305-8	350A412-28	350	115	10
